Feature:

1. Maximizes land use by utilizing vertical underground space. Telescopic column to suit small pit.
2. Reduces surface clutter and enhances the aesthetic appeal of an area.
3. Provides secure and weather-protected parking.
4. Residential buildings, commercial spaces, office complexes, and hotels.
5. Ideal for urban areas where surface space is at a premium.




Specifications:

Model No.CSL-3
Lifting Capacity2500kg/customized
Lifting Heightcustomized
Self Closed Heightcustomized
Vertical Speed4-6 M/Min
External Dimensioncustmized
Drive Mode2 Hydraulic Cylinders
Vehicle Size5000 x 1850 x 1900 mm
Parking Mode1 on the ground, 1 underground
Parking Space2 cars
Rise/Drop Time70 s / 60 s/ adjustable
Power Supply / Motor Capacity380V, 50Hz, 3Ph, 5.5Kw


Drawing
