Multi-Level Car Stacker System | 3 & 4 Level Parking Solutions for Commercial Use

Quad Stacker 4 Car Lift Car Parking Lifts

Description

Store more vehicles, use less ground. Our multi-level parking system is engineered for high-throughput environments — from airport drop-off zones and car dealerships to fleet yards and valet facilities — handling diverse vehicle types with consistent, heavy-duty reliability.

(0 Customer Reviews)

Product Feature

Feature:

Flexible Level Configuration
Available in 3 or 4-level arrangements to match site needs and future growth.
Row-Expandable Structure
Install as single units or extend into continuous rows for layouts of any scale.
Dedicated Hydraulic Drive
Self-contained hydraulic system ensures smooth, precise, and dependable lifting.
Key-Switch Access Control
Simple key operation limits use to authorized personnel in any facility type.
Integrated Safety System
Auto-locks, pressure relief valves, and overload detection protect every lift cycle.
Low Maintenance Design
Efficient mechanics minimize servicing needs and reduce long-term operating costs.
Improved Land ROI
Boosts parking density on existing footprints without major structural investment.

Product Introduction

Model No.	CQSL-3	CQSL-4
Lifting Capacity Per Platform	3000 kg
Lifting Height	2150 mm
Usable Platform Width	2405 mm
Overall Height	7503 mm	10093 mm
Overall Length	4947 mm
Overall Width	2945 mm
Power Supply / Motor Capacity	380V, 50Hz / 60Hz, 3Ph, 7.5Kw
Operation Mode	Key Switch + Button
Lock Release	Manual Lock Release Handle
Drive Mode	Hydraulic Drive + Steel Wire Rope
